專家測評：安裝快、產量高、易維護、智能化，適用于普通公路、高等級公路、高速公路及城市道路、運動場、機場、碼頭等基層穩定材料施工，能夠?qū)崿F(xiàn)連續生產多種攪拌均勻、配比準確的基層穩定材料。
● 模塊化的結構設計，安裝方便，轉場迅速
● 采用先進的集中微機配料控制系統，物料的配比精度和整機的工作效率都得到大大提高；
● 所有物料均采用電子計量稱進行計量，變頻調速控制，計量精度更高；
● 攪拌主機采用無襯板攪拌技術，徹底避免葉片和襯板磨損，維護方便；
| 型號 | SjWBZ300-3S | SjWBZ400-3S | SjWBZ500-3S | SjWBZ600-3S | SjWBZ700-3S | SjWBZ800-3S | SjWBZ10A-3B |
| 額定生產率(t/h) | 300 | 400 | 500 | 600 | 700 | 800 | 1000 |
| 攪拌主機 | |||||||
| 攪拌功率(kW) | 2X2X22 | 2X2X22 | 2X2X30 | 2X2X37 | 2X2X37 | 2X2X45 | 2X2X75 |
| 骨料粒徑 | ≤50 | ≤50 | ≤50 | ≤50 | ≤50 | ≤50 | ≤50 |
| 骨料倉容積(m3) | 4X12 | 4X12 | 4X12 | 5X12 | 5X12 | 5X15 | 5X15 |
| 皮帶機輸送能力(t/h) | 300 | 400 | 500 | 600 | 700 | 800 | 1000 |
| 稱量范圍及計量精度 | |||||||
| 骨料 | ±2% | ±2% | ±2% | ±2% | ±2% | ±2% | ±2% |
| 水泥 | ±1% | ±1% | ±1% | ±1% | ±1% | ±1% | ±1% |
| 水 | ±1% | ±1% | ±1% | ±1% | ±1% | ±1% | ±1% |
| 整機功率(kW) | 162 | 162 | 208 | 243 | 243 | 295 | 435 |
| 卸料高度 | 3.6 | 3.6 | 3.6 | 3.6 | 3.6 | 3.6 | 3.6 |
| 型號 | SjWBZ300-3S | SjWBZ400-3S | SjWBZ500-3S | SjWBZ600-3S | SjWBZ700-3S | SjWBZ800-3S | SjWBZ10A-3B |
| 額定生產率(t/h) | 300 | 400 | 500 | 600 | 700 | 800 | 1000 |
| 攪拌主機 | |||||||
| 攪拌功率(kW) | 2X2X22 | 2X2X22 | 2X2X30 | 2X2X37 | 2X2X37 | 2X2X45 | 2X2X75 |
| 骨料粒徑 | ≤50 | ≤50 | ≤50 | ≤50 | ≤50 | ≤50 | ≤50 |
| 骨料倉容積(m3) | 4X12 | 4X12 | 4X12 | 5X12 | 5X12 | 5X15 | 5X15 |
| 皮帶機輸送能力(t/h) | 300 | 400 | 500 | 600 | 700 | 800 | 1000 |
| 稱量范圍及計量精度 | |||||||
| 骨料 | ±2% | ±2% | ±2% | ±2% | ±2% | ±2% | ±2% |
| 水泥 | ±1% | ±1% | ±1% | ±1% | ±1% | ±1% | ±1% |
| 水 | ±1% | ±1% | ±1% | ±1% | ±1% | ±1% | ±1% |
| 整機功率(kW) | 162 | 162 | 208 | 243 | 243 | 295 | 435 |
| 卸料高度 | 3.6 | 3.6 | 3.6 | 3.6 | 3.6 | 3.6 | 3.6 |
